External Sleeve Choke Valve with Electric Actuator

Control Chokes
Are designed to provide precise flow control throughout their entire operating range. These chokes are available with either plug and cage trim, external sleeve trim or disk stack trim and are suitable for single or multi-phase liquid and gas service. Typical applications include Christmas trees, line heaters, manifolds, water injection and gas lift.
With their linear flow characteristics, Cameron’s Control
Chokes are ideal for automated applications.
Additional features of the
Control Choke includes:
Variety of flow characteristics.
Ability to withstand a wide range of operating conditions, including high sand concentrations.
Available in manually operated or actuated models.

External Sleeve
The External Sleeve Control Choke has a sleeve that throttles the flow on the outside diameter of the ported cage. This choke is used for low-capacity/high-pressure drop applications.
The external sleeve is specifically designed for severely erosive service where the combination of high-pressure drops and high sand concentrations can reduce the life of a choke

Plug and cage choke valve product description

As a professional fluid control equipment supplier, we are honored to recommend to you our star product - the plug and cage choke valve. With its unique design, performance, and wide range of applications, this valve has become an in industrial fluid control.
1. Product Overview
The plug-and-cage choke valve is a fluid control valve using plug and plug-and-cage throttling design. Its unique structure enables the valve to exhibit performance in fluid control. By adjusting the position of the plug within the cage structure, precise control of fluid flow and pressure can be achieved. This valve is suitable for a variety of fluid media, such as liquids, gases, etc., and is widely used in petrochemical, electric power, metallurgy, natural gas transportation and distribution, and other fields.

2. Performance characteristics
(1). Precise throttling and flow control
The plug-and-cage choke valve enables precise control of fluid flow through its unique plug and cage throttling design. The position of the plug in the cage structure can be fine-tuned to change the flow area of the fluid and achieve precise adjustment of the fluid flow rate and flow rate. This precise throttling design enables the valve to meet various complex process requirements and ensure a stable flow of fluid in the pipeline.
(2). Stable and reliable performance
The valve is made of high-strength, corrosion-resistant materials to ensure that the valve can maintain stable performance even in harsh working environments. Whether it is high temperature, high pressure, or corrosive media, a plug and cage choke valve can demonstrate durability and reliability, ensuring accuracy of fluid control and long-term stable operation.
(3). Good adjustment performance
The valve has regulating performance and can regulate smoothly over a wide flow range. Whether the flow needs to be increased or decreased, the valve responds quickly and adjusts precisely to the required flow value. This good regulating performance enables the valve to cope with various changing process conditions and maintain the stability and consistency of fluid control.
(4). Low noise and low vibration
The plug and cage choke valve produces low noise and vibration when operating, thanks to its unique design and optimized internal structure. The characteristics of low noise and low vibration make the valve more suitable for places with strict requirements on noise and vibration in the working environment, such as hospitals, laboratories, etc.
(5). Easy to maintain and operate
The valve is designed with user ease of operation and maintenance in mind. Its compact structure and easy disassembly and replacement of components allow users to easily perform valve maintenance and repair work. In addition, the valve is equipped with clear instructions and operating instructions to facilitate daily operations and adjustments.

3. Application fields
Plug and cage choke valve is widely used in many industrial fields due to their performance and reliable control capabilities. Whether you need to precisely control fluid flow or regulate fluid pressure, this valve provides a solution. The following is a detailed introduction to the application fields of plug and cage choke valves:
(1). Petrochemical industry
In the petrochemical industry, plug, and cage choke valves play a vital role. It is used in crude oil transportation, oil refining equipment, oil and gas pipelines and other occasions to accurately control the flow and pressure of crude oil, refined oil, natural gas, and other fluids. By adjusting the opening of the valve, the stable flow of fluid can be ensured, overloading or underloading can be prevented, production safety can be ensured, and production efficiency can be improved.
(2). Electric power industry
In the power industry, fluid control is critical to the stable operation of power generation equipment. Plug and cage choke valve is often used in key parts such as boiler water supply systems and steam control systems. By accurately adjusting the opening of the valve, the flow of water and steam can be controlled to ensure the normal operation of power generation equipment, improve power generation efficiency, and reduce energy consumption.
(3). Metallurgical industry
In metallurgical processes, flow and pressure control of fluids such as molten metal and gas are crucial to product quality and production efficiency. Plug and cage choke valve is widely used in smelting furnaces, rolling lines and other processes. By accurately adjusting the opening of the valve, the stability of the smelting process and product quality can be ensured, and production efficiency can be improved.
(4). Natural gas transportation and distribution
In the field of natural gas transmission and distribution, plug and cage choke valve also plays a key role. It is used in key links such as natural gas pipelines and gas storage facilities to accurately control the flow and pressure of natural gas. By reasonably adjusting the opening of the valve, the needs of different users can be met and the rational distribution and utilization of natural gas can be achieved.
(5). Environmental protection and water treatment fields
With the increasing awareness of environmental protection, fluid control is becoming more and more important in the fields of environmental protection and water treatment. Plug and cage choke valves can be used in processes such as sewage treatment and wastewater recycling to accurately control the flow of fluids and achieve effective treatment of wastewater and resource recovery. In addition, it can also be used in water supply treatment, industrial circulating water systems, and other occasions to ensure the safety and stability of water quality.
In addition to the above main application fields, plug and cage choke valves can also be used in other industrial fields according to specific needs, such as the chemical industry, pharmaceuticals, papermaking, etc. Its performance and wide range of applications make it an indispensable device in the field of industrial fluid control.

4. Customized services
We understand that different customers have different needs, so we provide customized plug and cage choke valve services. Customers can choose suitable valve materials, specifications, and performance parameters based on specific process requirements, fluid media, and working environment. Our professional team will provide customers with technical support and solutions to ensure that products can meet customers' specific needs.

5. Quality assurance
We always adhere to quality as the core and strictly control the production process to ensure that every plug and cage choke valve meets high-quality standards. We have a complete quality management system and advanced testing equipment and strictly control every production process to ensure product stability and reliability.
